| ∅ D inch |
∅ D mm |
L mm |
I mm |
| 1/64 | 0,397 | 20 | 5 |
| 1/32 | 0,794 | 30 | 10 |
| 3/64 | 1,191 | 38 | 16 |
| 1/16 | 1,588 | 43 | 20 |
| 5/64 | 1,984 | 49 | 24 |
| 3/32 | 2,381 | 57 | 30 |
| 7/64 | 2,778 | 61 | 33 |
| 1/8 | 3,175 | 65 | 36 |
| 9/64 | 3,572 | 70 | 39 |
| 5/32 | 3,969 | 75 | 43 |
| 11/64 | 4,366 | 80 | 47 |
| 3/16 | 4,763 | 86 | 52 |
| 13/64 | 5,159 | 86 | 52 |
| 7/32 | 5,556 | 93 | 57 |
| 15/64 | 5,953 | 93 | 57 |
| 1/4 | 6,350 | 101 | 63 |
| 17/64 | 6,747 | 109 | 69 |
| 9/32 | 7,144 | 109 | 69 |
| 19/64 | 7,541 | 117 | 75 |
| 5/16 | 7,938 | 117 | 75 |
| 21/64 | 8,335 | 117 | 75 |
| 11/32 | 8,732 | 125 | 81 |
| 23/64 | 9,128 | 125 | 81 |
| 3/8 | 9,525 | 133 | 87 |
| 25/64 | 9,922 | 133 | 87 |
| 13/32 | 10,319 | 133 | 87 |
| 27/64 | 10,716 | 142 | 94 |
| 7/16 | 11,113 | 142 | 94 |
| 29/64 | 11,510 | 142 | 94 |
| 15/32 | 11,907 | 151 | 101 |
| 31/64 | 12,304 | 151 | 101 |
| 1/2 | 12,700 | 151 | 101 |
| 33/64 | 13,097 | 151 | 101 |
| 17/32 | 13,494 | 160 | 108 |
| 35/64 | 13,891 | 160 | 108 |
| 9/16 | 14,288 | 169 | 114 |
| 37/64 | 14,685 | 169 | 114 |
| 19/32 | 15,082 | 178 | 120 |
| 39/64 | 15,479 | 178 | 120 |
| 5/8 | 15,876 | 178 | 120 |
| 41/64 | 16,272 | 184 | 125 |
| 21/32 | 16,669 | 184 | 125 |
| 43/64 | 17,066 | 191 | 130 |
| 11/16 | 17,463 | 191 | 130 |
| 45/64 | 17,860 | 191 | 130 |
| 23/32 | 18,257 | 198 | 135 |
| 47/64 | 18,654 | 198 | 135 |
| 3/4 | 19,051 | 205 | 140 |
| 49/64 | 19,448 | 205 | 140 |
| 25/32 | 19,844 | 205 | 140 |
| 51/64 | 20,241 | 210 | 145 |
| 13/16 | 20,638 | 210 | 145 |
| 53/64 | 21,035 | 210 | 145 |
| 27/32 | 21,432 | 215 | 150 |
| 55/64 | 21,829 | 215 | 150 |
| 7/8 | 22,226 | 215 | 150 |
| 57/64 | 22,623 | 220 | 155 |
| 29/32 | 23,020 | 220 | 155 |
| 59/64 | 23,416 | 220 | 155 |
| 15/16 | 23,813 | 225 | 160 |
| 61/64 | 24,210 | 225 | 160 |
| 31/32 | 24,607 | 225 | 160 |
| 63/64 | 25,004 | 225 | 160 |
| 1 | 25,400 | 250 | 165 |
